Sensors
Number of Beams
6 pairs
Beams Spacing
40mm
Protection Height
00mm
Detection Distance
0.5-m
Working Voltage
DC24V±10%; Max applicable voltage range: 10-30V
Power Consumption
5W
Power Consumption
NPN/PNP
Response Time
Housing Material
Aluminum Alloy (yellow)
Detection Method
Through beam
Ambient Temperature
Insulation Resistance
>100MQ
Anti-in terferance
WOOOLux (Angle of incidences 5°)
Connection
Emitter: M8 connector cable (3 pins with 3 wire)
Receiver: M8 connector cable (4 pins with 4 wire)
Protection
Reverse connection Protection/ Output short circuit protection
Dielectric Strength
AC1500V.60S
Working Temperature
-15°C + 65°C
Storage Temperature
-25°C + 75°C
Section Size
18*35mm
MODEL
NUMBER OF BEAMS
SPACING
PROTECT HEIGHT
JPPER COVER HEIGHT
BLIND ZONE
DOWN COVER HEIGHT
INSTAL
HOLE
DISTANCE
TOTAL HEIGHT
H(mm)
C(mm)
A(mm)
B(mm)
D(mm)
E(mm)
F(mm)
G(mm)
APS18-0440NB
4 40
120
12
20
35
12
187
199
APS18-0640NB
6 40
200
12
20
35
12
267
279
APS18-0840NB
8 40
280
12
20
35
12
347
359
APS18-1040NB
10
40
360
12
20
35
12
427
439
APS18-1240NB
12
40
440
12
20
35
12
507
519
APS18-1440NB
14
40
520
12
20
35
12
587
599
APS18-1640NB
16
40
600
12
20
35
12
667
679
APS18-1840NB
18
40
680
12
20
35
12
747
759
APS18-2040NB
20
40
760
12
20
35
12
827
839
APS18-2240NB
22
40
840
12
20
35
12
907
919
APS18-2440NB
24
40
920
12
20
35
12
987
999
APS18-2640NB
26
40
1000
12
20
35
12
1067
1079
APS18-2840NB
28
40
1080
12
20
35
12
1147
1159
APS18-3040NB
30
40
1160
12
20
35
12
1227
1239
APS18-3240NB
32
40
1240
12
20
35
12
1307
1319
APS18-3440NB
34
40
1320
12
20
35
12
1387
1399
APS18-3640NB
36
40
1400
12
20
35
12
1467
1479
APS18-3840NB
38
40
1480
12
20
35
12
1547
1559
APS18-4040NB
40
40
1560
12
20
35
12
1627
1639
APS18-4240NB
42
40
1640
12
20
35
12
1707
1719
APS18-4440NB
44
40
1720
12
20
35
12
1787
1799
APS18-4640NB
46
40
1800
12
20
35
12
1867
1879
APS18-4840NB
48
40
1880
12
20
35
12
1947
1959
APS18-5040NB
50
40
1960
12
20
35
12
2027
2039
APS18-5240NB
52
40
2040
12
20
35
12
2107
2119
APS18-5440NB
54
40
2120
12
20
35
12
2187
2189
APS18-5640NB
56
40
2200
12
20
35
12
2267
2279
APS18-5840NB
58
40
2280
12
20
35
12
2347
2359
APS18-6040NB
60
40
2360
12
20
35
12
2427
2439
APS18-6240NB
62
40
2440
12
20
35
12
2507
2519
APS18-6440NB
64
40
2520
12
20
35
12
2587
2599
APS18-6640NB
66
40
2600
12
20
35
12
2667
2679
APS18-6840NB
68
40
2680
12
20
35
12
2747
2759
==========
Material : Aluminium alloy
Switch Type : Switch
Model Number : APS18-0640
Features : 18mm super thin type
Item Type : SWITCHES
Model : APS18-0440
Model1 : APS18-0640
Cable length : 2.8 meter
Detection distance : 0.5-2m
