Needle-Bearing
Wire length: 200mm
Shell material: engineering plastic
Contact material: precious metal/gold-gold
Product number
SRM022-3R5A
Contact material
Precious Metals/Gold -
Number of channels
3 way
Shell material
Engineering plastics
Rated voltage
Compatible below 0～240VAD/DC
Torque
0.04Nm
Insulation resistance
≥1000MΩ/500VDC
Protection level
IP51
Product outer diameter
∅22mm
Working humidity
10%～90%RH
Wire specifications
AWG20 silver plated
Wire length
Standard 250mm
Working speed
0～250rpm
Current size
5A/each channel
working temperature
-10℃～+80℃
dynamic resistance
