Needle-Bearing
Model: ZHT025-4R30A&2R2A
Custom processing: Yes
Part Number: ZHT025-4R30A&2R2A

model
ZHT025-4R30A&2R2A
Number of channels
4
Rated current
30 A/channel + 2 channels 2A signal
Rated voltage
240VAC/DC
Speed
0-250rpm
outer diameter
ø25mm
Contact material
Precious Metals
Shell material
Aluminum Alloy
Dynamic resistance
Minimum 1mΩ
noise
Wire Specifications
AWG12
Compressive strength
500VDC@50Hz,10s
Wire length
Standard 250 mm
Dielectric strength
500mΩ@500VDC,10s
Protection level
IP54
Operating temperature
-20℃ ~+60℃ (recommended)
Operating humidity
10%-85% RH
Shockproof level
MIL-STD-810E
