25Gb/s SFP28 850nm 100M LC SMF VCSEL PIN Optical SFP Transceivers DOM
General
The based 25Gigabit SFP28 Transceiver is designed to transmit and receive serial optical data over multimode optical fiber with100m.
They are compliant with SFF-8431,SFF-8432. The transmitter converts serial CML electrical data into serial optical data compliant with the IEEE802.3by standard. The receiver converts serial optical data into serial CML electrical data.Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF-8472.
Features
Operating data rate up to25.78Gbps
High sensitivity Pin photodiode and TIA
Up to 70m transmission on MMF OM3 and 100m transmission on MMF OM4
LC duplexconnector
pluggable 20pinconnectorl
0to 70operating wide temperaturerange
Single +3.3V±5% powersupply
Digital Monitoring SFF-8472
Fully RoHSCompliant
Applications
25G Ethernet Switchesand Routers
FiberChannel Switch Infrastructure
25Gb/s Fibre Channel
When bidding the product, please leave message for your switch .
25G SFP Transceivers
25G SFP
SFP28-25G-SR
SFP28 25Gbps 850nm 100M LC DOM
SFP28-25G-LR
SFP28 25Gbps 1310nm 10KM LC DOM
SFP28-25G-ER
SFP28 25Gbps 131nm 40KM LC DOM
