Needle-Bearing
Specification:
Outer diameter: 22 mm
Channels: 2 + 4
Rated current: 2CH 10A + 4CH 2A
Rated voltage: AV/DC 220V
- Speed: 250rpm/min
- Insulation resistance: 500M@500VDC
- noise: 10m@6VDS, 50mA, 5Rpm
- Operating temperature: -40~+80
Operating humidity: 60%RH
Protection level: IP54
- Contact material: precious metal
- Shell material: engineering plastic
Torque: 0.02NM
- Bearing: High precision ball bearing
Cable Type: AWG16 + AWG28
Cable length: 250mm
Note: The size is measured manually, there may be errors
