Needle-Bearing
Specification:
Diameter: 22 mm
Channels: 2 channels/3 channels/4 channels/6 channels/8 channels/12 channels
Rated current: 5A
Rated voltage: 220VAC/DC
- Speed: Maximum 200rpm
Operating temperature: -20~+60
- Contact material: Gold/Gold
- Cable length: standard 200mm
- Withstand voltage: 500V 50Hz between two channels
- Insulation resistance: 1000m 500VDC
- Dynamic resistance fluctuation value: minimum 10m
Shell material: engineering plastic
- Working life: 5 million rpm (depending on working environment and speed)
