Dosing Pumps
Hign-concerned Chemical : None
Application : Metering
Theory : Rotary Pump
Structure : Gear Pump
Standard or Nonstandard : Standard
Pressure : Low Pressure
Fuel : Electric
Origin :
Power (W) : Electric
Voltage : DC24V; 1.6A Max
Accuracy : 1.0%(1 ml syringe and above)
Max pressure reference value of the liquid circuit : Positive pressure:0.7Mpa Negative pressure 0.08Mpa
Rated stroke : 30mm
Running time(per rated stroke) : 1.26s-1200s
Syringe configuration : 50uL, 100uL, 250uL, 500uL, 1mL, 2.5mL, 5mL
Noise : 55dB
Size(L*W*H) : 133.6*44.5*127mm(Including pump head)
