Needle-Bearing
describe
- Material: Aluminum Alloy
Outer diameter: 7.9mm
Length: 25 mm
Weight: Approx. 4.3 g
Wires: 8
Specification:
- Current: 1A/channel
Voltage: 250 VDC/VAC
Maximum speed: 250rpm
- Working life: >20 million rotations (depending on speed and environment)
- Compressive strength: 500VDC/50Hz, 10s
- Dielectric strength: 1000m O / 600DC, 10s
- Wire specification: AWG30
Cable length: 250mm
Working temperature: ~40~85 degrees
Protection level: IP51
Shockproof level: MILSTD 810E
Operating humidity: 10%~85%RH
