Pillow Blocks
These bearings are made of high-quality bearing steel long life with low noise.
6700 Series \u2013 Metric dimensional series for very limited space applications and very light loads
6800 Series \u2013 Metric dimensional series for limited space applications and light loads
63800 Series \u2013 A hybrid between the 6800 and 6900 Series with the load capacities of the 6800 series but the width of the 6900 series.
6900 Series \u2013 Metric dimensional series for limited space applications and heavier loads
TECH DEATAILS
Item: 6909-2RS
Structure: Thin Section Ball Bearing
Material: 52100 Chrome Steel
Bore Dia (d): 45 mm
Outer Dia (D): 68 mm
Width (B): 12 mm
Clearance: C0
Grades: ABEC-1
Lubrication: With Grease
Weight: 128 g
Quantity: 1 Lot = 5 PCS
Item: 6910-2RS
Structure: Thin Section Ball Bearing
Material: 52100 Chrome Steel
Bore Dia (d): 50 mm
Outer Dia (D): 72 mm
Width (B): 12 mm
Clearance: C0
Grades: ABEC-1
Lubrication: With Grease
Weight: 133 g
Quantity: 1 Lot = 5 PCS
Item: 6908-2RS
Structure: Thin Section Ball Bearing
Material: 52100 Chrome Steel
Bore Dia (d): 40 mm
Outer Dia (D): 62 mm
Width (B): 12 mm
Clearance: C0
Grades: ABEC-1
Lubrication: With Grease
Weight: 118 g
Quantity: 1 Lot = 5 PCS
Item: 6911-2RS
Structure: Thin Section Ball Bearing
Material: 52100 Chrome Steel
Bore Dia (d): 55 mm
Outer Dia (D): 80 mm
Width (B): 13 mm
Clearance: C0
Grades: ABEC-1
Lubrication: With Grease
Weight: 177 g
Quantity: 1 Lot = 5 PCS
Features &Application
Small size and lightweight
In the most popular type of bearings the 6000 series the required space for their installation will be reduced to about 13
Various sealing types
Wide choices are available in mounting methods and lubrication system for shielded type non-contact type sealed and con
