Cross Roller Guides
describe:
1. This metric linear translation stage is a high-precision linear platform with a travel of 13 mm (± 6.5 mm) and an area of ​​60*60 mm.
2. This guide rail is made of high-precision steel balls and carefully made steel rods, with high precision
3. The locking mechanism ensures that the platform remains in a stable position with little movement when the platform is engaged and disengaged
scope:
1. Moving axis: X&Y
2X and Y direction travel 13mm
3. Load capacity: 4kgf (39.2N)
4. Bearing: ball bearing
5.Main material: aluminum alloy
6. Minimum scale: 0.01mm
7. Accuracy: 0.01mm
8. Parallelism: 0.03mm
9.Weight: 0.42kg
