Needle-Bearing
Specification:
Speed: Maximum 250rpm
Number of channels: 2, 3, 4, 6, 8 channels optional
Rated voltage: 220VAC/DC
Rated current: 10A/channel
Diameter: 22 mm
Working temperature: -20～+60
Contact material:
Wire size: AWG17 silver-plated UL
Cable length: standard 200mm
Withstand voltage: 500V 50Hz between two channels
Insulation resistance: 500M/500VDC
Dynamic resistance fluctuation value: minimum 10m
Shell material: Engineering plastic
Working life: 5 million revolutions (depending on working environment and speed)
