Needle-Bearing
parameter:
Speed: 150RPM
Number of channels: 2/3/4//6/8/12/18/24 lines
Rated voltage: 240VAC/VDC, 440VAC/VDC
Rated current: 2A/5A/10A/15A/30A
Working temperature: -30～+80
Contact Materials: Plastic and
Wire specification: AWG17#, AWG22# silver-plated UL
Cable length: standard 150mm
Withstand voltage: 300V, 500V 50Hz between two channels
Insulation resistance: 300M/300VDC, 500M/500VDC
Shell material: engineering plastic/metal
or not: No
