Specification:
Item Type: High Voltage Megohmmeter

Material: ABS

Measuring Range: -10.0°C-60.0°C, Maximum Display: 60.0°C, Resolution: 0.1°C, Testing : ±1.0°C

Measuring Current: 20A, Measurement Range: 10.0uΩ-1000.0uΩ, : ±0.2%FS±10dgt, Resolution: 0.1uΩ

Measurement Range: 1.000mΩ-10.000mΩ, : ±0.2%FS±10dgt, Resolution: 0.001mΩ

Measuring Current: 10A, Measurement Range: 10.00mΩ-100.00mΩ, : ±0.2%FS±10dgt, Resolution: 0.01mΩ

Measuring Current: 5A, Measurement Range: 100.0mΩ-1000.0mΩ, : ±0.2%FS±10dgt, Resolution: 0.1mΩ

Measuring Current: 1A, Measurement Range: 1.000Ω-10.000Ω, : ±0.2%FS±10dgt, Resolution: 0.001Ω

Measuring Current: 0.1A, Measurement Range: 10.00Ω-100.00Ω, : ±0.2%FS±10dgt, Resolution: 0.01Ω

Measuring Current: 10mA, Measurement Range: 100.0Ω-1000.0Ω, : ±0.2%FS±10dgt, Resolution: 0.1Ω

Measuring Current: 1mA

Measurement Range: 1.000KΩ-10.000KΩ, : ±0.4%FS±30dgt, Resolution: 0.001KΩ

Measurement Range: 10.00KΩ-100.00KΩ, : ±0.4%FS±30dgt, Resolution: 0.01KΩ

Measurement Range: 100.0KΩ-1000.0KΩ, : ±1%FS±30dgt, Resolution: 0.1KΩ

Temperature Characteristics: Use temperature range plus test x​​​ 0.3/°C. (Outside of 18℃ to 28℃)

Calculation Method: = ( Current Gear ) + 0.3x(Temperature Difference Number) x (Current Gear )

Example: Use of the environment 8 ℃ / 20A current gear The of the gear ± 0.2% FS ± 10dgt

= (0.2%FS±10dgt) + 0.3×10×(0.2%FS±10dgt) = 0.8%FS±40dgt

(Note: 1mA current 1000K level test is only valid from 18℃ to 28℃)

Technical specifications

Function: It is mainly used measuring DC resistor of transformer, winding resistor of transformer, conductivity of ground network connection, wire resistor of cable, contacting resistor of switch, connector, relay, resistor of coil, motor and transformer winding as well as metal riveting resistor, resistor test of coupling between metal
