Features:
1) The structure of the self-locking, easy to install, portable
2) Wide inner window, allowing clamping of big cables or bus-bars
3) Wide range of sizes to accommodate all the existing installations
4) Isolated case recognized
5) Wires plugs, Audio plugs, Power plugs and so on five kinds of plugs
6) High accuracy class ,wide linearity
7)Superitor stability ,separate the external magneitc field interference
8)Measure the current directly
1m wire
Accuracy: class 1
Application: Electricity Measuring
Operating Temperature: -40°C~+70°C
Ratio:100/5A 150/5A,200/5A,250/5A,300/5A,400/5A
Split Core
Window Hole size:24MM
Applications:
1:Current measurement, protection for electrical wiring and equipment.
2:Current and power measurement for electric motors, lighting, aircompressor,heating and ventilation system, air-condition equipment and automation control system.
3:Current, power and energy device.
4:Relay protection device.
