10 قطعة 12 دبوس 2.54 مللي متر الملعب PCB الأخضر محطة كتلة ، 150 فولت 6A جبل المسمار موصل طرفي لكابل 26-18AWG (12pin) in Saudi Arabia

10 قطعة 4 دبوس 2.54 مللي متر الملعب PCB الأخضر محطة كتلة ، 150 فولت 6A جبل المسمار موصل طرفي لكابل 26-18AWG (10pin)

SAR 53
اللون10pin
– 1 +

مميزات خاصة

  • The pin of the PCB screw terminal block is made of brass, which has good electrical conductivity. The shell of the PCB terminal block is made of plastic, flame-retardant and insulated, ensuring safety during use.
  • PCB terminal connectors are widely used in low frequency PCB wiring, 2.54mm pitch screw terminals are suitable for electronics, communication equipment, household appliances and alarm devices.
  • PCB Screw Terminal Block Connector Made of ABS Plastic, Electric Parts; Screw Terminals Wire Sizes: 18AWG to 26AWG
  • PCB terminal block is simple to solder and easy to assemble. The PCB terminal block cannot be spliced, please select the pin size you need when purchasing.
  • 10pcs PCB Connectors 2.54mm 0.1" Pitch Screw Terminal Block Connector 150V 6A PCB Terminal Block Connector

وصف

Specification:
Pitch: 2.54mm/0.1”
Pin Header: Brass, Tin plated
Screw: M1.6, Steel,Tin plated
Clips: Stainless Steel
Housing: PA66, UL94V-0
Rated Voltage: 150V
Rated Current: 6A
Withstanding Voltage: AC 1250V/ 1Min
Wire Range: 26-18AWG(UL)
Wire Range: 1mm2(IEC)
Temperature Range: -40° ~ +105°
Stripping Length: 5-6mm
Maximum Tightening Torque: 0.1Nm(0.88lb-in)Package Contents:
10 x Screw Terminal Block
