مميزات خاصة

Safe Wiring Connection: 4-pole through-wall screw terminal, rated 300V 8A. Provides stable and safe electrical connections for various devices.
Durable & Flame-Retardant: Made of PA66 high-temperature V0 flame-retardant material. No leakage, no short circuit, long service life.
Easy to Use: Loosen the screws, insert the wires, and tighten. Quick disconnect design makes device replacement fast and simple.
Strong Contact Design: Anti-vibration structure with tin-plated brass and nickel-plated phosphor bronze contacts for reliable conductivity.
Package: 5 Set 4pin (Male Plug+ sleeve+ female socket) Pitch: 3.81mm. Wire: 28–16AWG. Strip length: 5–8mm. Use M2.5 screws (not included).

وصف

Feature
-Type: Through-Wall Terminal Connectors
-Pin: 4 Pin
-Pitch: 3.81mm
-Gender: male & female
-Contact (Female Socket): Tin Plated Brass
-Contact (Male Plug): Nickel Plated Phosphor Bronze
-Plastic Components: PA66, Flame-Retardant
-Rated Value: 8A 300V
-Wire Range:16-28AWG
-Withstanding Voltage: AC1500V/1Min
-Torque:0.4Nm (3.5lb-In)
-Stripping length:7-8mm
-Temperature range:-113°F ~ + 221°F
-Screw and Push-in connection design
Package:
-5set x 4 Pin 3.81mm Pitch male plug & female socket PCB Terminal Block Connector
Notice:It's crucial to select terminal blocks that match the specifications of your project to ensure reliable connections and proper functionality within the circuit.
