Voltage
Suitable for hanging on the wall of the furnace, gas oven, gas storage, etc. all kinds of specifications, pneumatic pressure measurement.
Static precision: plus or minus 1.0% FS.
Pressure range 0-0.5 MPa
Wide range of temperature compensation.
Medium for non-corrosive gas, water, oil, etc .
Working Voltage: 5V DC
Output Voltage: 0.5-4.5V DC
Working Current: Less than or equal to 10 mA
The Highest Pressure: 1.5 MPa
Destroy Pressure: 3.0 MPa
Working TEMP. Range: 0-85 Degree Celsius
Storage Temperature Range: 0-100 Degree Celsius
Temperature Range Error: ±3.0 %FSO
Response Time: Less than or equal to 2.0 ms
Cycle Life: 500,000 times
Color: silver + black
Material: metal + ABS
Package Content: 1* Pressure Sensor
Only the above package content, other products are not included.
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
==========
Hign-concerned Chemical : None
