مميزات خاصة

reducer
High precision: Micron-level positioning; meets precision machining requirements
Long service life: Minimal wear; stable long-term operation
High speed and energy efficiency: Low friction；low energy consumption during high-speed movement
Strong load capacity: Four-way load bearing; suitable for heavy-duty applications
Easy maintenance: Simple structure; convenient installation and lubrication

وصف

reducer
1 X Sliding Table
1X NEMA23 Stepper Motor
1 X Free Coupling
Stroke:50-300MM
Effective Stroke: Stroke + 10 mm
Horizontal load: 40KG (Max)
Vertical load: 20KG(Max)
Mobile panel size: 80mm X 50mm
Repeat positioning: 0.02mm-0.05mm
Maximum speed: 100mm/s
GuideType: 2X12mm Optical axis rod
(Tips:SFU1605means:Screw Diameter 16mm pitch 5mm )Dimension :
MotorSpecifications :
Flange Size:57mm Nema23
Type: hybrid
Phase:2PH
Step Angle:1.8 deg
Holding torque: 1.2Nm/2.2Nm/3Nm
Shaft Diameter:8mm
Current:3.0A
Model Number : GGP5080-1605-50-300+57HS56/84/112A4D8
Guide Width or Diameter : 12mm
