【Panel-Mount】Fittings on the back let you install this flowmeter in instrument panels. Mount them vertically inline with your piping system, so liquid flows up from the bottom. As liquid passes through, it pushes an indicator up the scale, showing you the flow rate. The flow range is 0.05 to 0.5 gpm / 0.2 to 2 lpm
【Acrylic Body】With an acrylic plastic body and the white backing, this water flowmeter is completely clear, so you can inspect your liquid's color and clarity for any problems
【Pipe Connection】Flowmeters with a female נmale connection have internal 1/4" BSP female threads and external 1/2" BSP male threads
【Fitting Material】Choose a fitting material that is compatible with the liquid you're running through your line. PVC fittings work with a wide range of chemicals. However, they can crack from impact or when overtightened
【Other Liquids】This flowmeter is calibrated with water but can be used with other liquids. If you're using these with a liquid other than water, you'll need to calculate the flow rate by multiplying the number shown on the scale by the specific-gravity conversion factor for your liquid

وصف

SPECIFICATIONS

For Use With: Liquids
Calibrated With: Water
Calibration Media Specific Gravity: 1
Connections: Threaded Pipe × Threaded Pipe
Pipe Connections: 1/4" NPT Female × 1/2" NPT Male
Flow Measurement Type: Variable Area
Flow Measurement Scale: Gallons per Minute, Litre per Minute
Flow Range: 0.05 to 0. 5 gpm
Overall Height: 170mm / 6.69"
Accuracy: ±4%
Maximum Pressure: ≤0.6Mpa
Temperature Range: 0 to 60° C
Body Material: Acrylic Plastic
Fitting Material: PVC Plastic
Mounting Style: Panel
Mounting Orientation: Vertical
Display Type: Scale

Package Inlcudes:l
1 x Water Flowmeterl
【Warning Message】 Liquids compatibility must be determined by the customer based on the conditions in which the product is being used; including the presence of other chemicals, temperature, and consistencyl
