Technical Indicators And Specifications
Measuring range:
1.The diameter of the hole varies depending on the measurement range.
2.Hole diameter 22mm:AC0-50mA-500A,DC0-50mA-1000A.
3.Hole diameter 25mm:AC0-50mA-1000A,DC0-50mA-1000A.
4.Hole diameter 31mm:AC0-5A-1000A,DC0-5A-1000A.
Output:
1.Output signal: 4-20mA,0-20mA,0-5V,0-10V,RS485.
Power supply:
1.Can be made: 12V,15V,24V,12V-28VDC,220V.
Technical characteristics:
High measurement accuracy Stable and structure
Strong anti-interference ability Lightweight and easy to install
==========
Dimensions : See size chart
Operating Temperature : -10-70
Supply Voltage : 12V,24V,12V-28VDC
Accuracy Class : 0.2%F.S.,0.5%F.S.
Model Number : SWK-7
DIY Supplies : ELECTRICAL
Certification : ,FCC,
Measuring range : DC0-10A-500A
Output : 4-20mA,0-20mA,0-5V,0-10V
Power supply : ±12V,±15V,24VDC,12V-28VDC
Response time : 10ms
Installation method : Screw fixation
