Final Rating
Anode voltage: 480V
Anode dissipation power......40W
Cathode current
Self-bias voltage 100 mA
Fixed bias voltage 70 mA
Interelectrode capacitance
Input capacitance: 9PF
Output capacitance: 4.3PF
Cross-circuit capacitance: 15PF
Static parameters
Voltage...300V
Uh...60 volts
Current......60 mA
On-resistance......5.5 mA/V
Swiss... 0.7 K
......................... 3.85
pout
----------------Well
----------Ua Uf (AC) Uf (DC) Ia
----------V --~V --=V -- - mA
Recommended parameters - 33-29.5-77
---------200 {45--41.5--20
---------------46-42.6-74
---------250 {57--53.6--22
---------------60-56.5-68
---------300 {70--66.5--23
---------------86-82.5-68
---------400 {98-94.5-19
Limit parameters -450 100-96.5-60
