Specification: MIL-DTL-5015
Shielding: Yes
Connector Type: Circular
Connector Style: Plug
Mounting Type: Cable
Orientation: Straight
Endbell Type: Threaded - UNEF - Ext
Number of Contacts: 8
Contact Style: Pin
Termination Method: Solder
Insert Arrangement: 22-18
Contact Size: 8#16
Contacts Supplied: Yes
Contact Material: Brass or Copper Alloy
Contact Plating: Silver
Shell Material: Aluminum Alloy
Shell Plating: Olive Drab Chromate over Cadmium
Shell Color: Olive Drab
Insert Material: Diallyl Phthalate
Amperage Rating: 13A
Operating Voltage DC: 1250/700
Operating Voltage AC: 900/250
Operating Temperature: +257 (+125) for 60 hours, +185 (+85) for 1000 hours
Contact Mating life: 100
RoHS: No
Insert Rotation Keying: Normal
