1000:1
5A/5mA
10A/10mA
20A/20mA
30A/30mA
40A/40mA
50A/50mA
60A/60mA
80A/80mA
100A/100mA
2000:1
5A/2.5mA
10A/5mA
20A/10mA
30A/15mA
40A/20mA
50A/25mA
60A/30mA
80A/40mA
100A/50mA
Specifications
Frequency: 50-2KHz
Rated input: 5A-630A
Measurement range: 10% In -120% In
Rated output: 0.333V (AC) or 0-500mA
Error: ± 1.0%
Angle difference: ± 60min
Insulation strength: 2.5KV/1mA/1min
Insulation resistance: DC500V/100MQmin
Iron core: silicon steel
Internal structure: epoxy
Installation method: buckle
Working temperature: -25C~75C
==========
Phase : SINGLE
Origin : Mainland China
Use : Current
