Nema17 Open-loop Stepper Motor
Model: S42HS series
Motor type: Hybrid open-loop stepper motorFlange size:Nema17 42*42mmStep Angle: 1.8°
Phase: 2 Phase
Holding Torque (Body Length):0.32Nm(34mm)/ 0.5Nm(40mm)/ 0.62Nm(48mm)/ 0.88Nm(60mm)
TB6600 Drive:
Model:TB6600Input voltage:DC 9-42VInput/ Output current:0.5-3.5AMaximum power: 150WSubdivision:1 2 4 8 16 32Operating environment temperature:-10-45Storage temperature:-40-70
Nema17 Closed-loop Stepper Motor Driver All-in-one:
Model: TST42 seriesRated torque: 0.4Nm/ 0.5Nm/ 0.6NmMotor shaft diameter:5mm/8mm
Motor type: Closed-loop stepper motor driver all-in-oneInput voltage: 24VDC~48VDCOutput current: 2A/2.5AInput:factory default 3 channels can receive 3.3-24V directlyOutput: factory default 1 circuit maximum withstand voltage 30VCommunication mode: TTLCommunication interface: Micro USBWorking mode: single and double pulse dialing is optional and IO control can be set through upper computer
Certification : CE
Origin : CN (Origin)
Model Number : Y200RA60
Stroke : 360° rotation
Guide : Bearing
through-hole diameter : 0/30mm
table size : 60-400mm
