HIFI 101D low voltage power amplifier tube.
Typical operating parameters
Filament voltage: 4.5V
Filament current: 1.0A
Anode voltage: 190V
Gate voltage: -14V
Anode current: 10mA
Magnification: 6.2
Output power: 200mW
Interelectrode capacitance
Input capacitance: 6.4pF
Output capacitance: 4.4pF
Inter-circuit capacitance: 2.9pF
Limit parameters: (minimum and maximum units)
Filament voltage: 45V
Anode voltage: 400V
Anode dissipation power: 15W
Anode current: 20mA
