14 Pin DIP IC Socket, 2.54mm Pitch 7.62mm Spacing, Round Machine Pin Solder Type, Through-Hole PCB Mount, 30-Pack in Saudi Arabia

18P

SAR 50
Brand
GANASOME
Weight
23 g
Length18P
– 1 +

Special Features

  • Reliable IC Interface: Provides a durable and replaceable connection point for 14-pin DIP ICs, protecting sensitive chip leads from direct soldering heat and mechanical stress during prototyping or repairs.
  • Standard PCB Footprint: Designed with universal 2.54mm (0.1") pin pitch and 7.62mm (0.3") row spacing, ensuring perfect compatibility with standard PCB layouts and automated assembly processes.
  • Robust Construction: Features round machine pin (turn pin) contacts for superior connectivity and a high-temperature PBT plastic housing that withstands soldering temperatures.
  • Extended Application: Ideal for a wider range of integrated circuits, commonly used in prototype development, test fixtures, industrial controls, and for sockets on 14-pin DIP chips (e.g., common Op-amps, drivers, logic ICs).
  • Package & Clarification: Contains 30 pieces of 14-pin DIP IC sockets. Note: This listing is for sockets only. IC chips, PCB boards, or any additional components are not included.

Description

This DIP-14 socket is engineered as a critical interconnect component for printed circuit board (PCB) design and repair. Its primary function is to offer a reliable, socketed interface for 14-pin Dual In-line Package (DIP) integrated circuits, facilitating safe installation and field replacement.

The socket utilizes precision round pin contacts, which provide a more stable and gas-tight connection with the IC leads compared to flat stamped pins. The glass-reinforced PBT thermoplastic material ensures dimensional stability during wave or hand soldering operations and offers high heat resistance.

This component is essential in applications where circuit configuration may change, expensive ICs require protection, or maintenance ease is a priority, such as in industrial control modules, legacy system repairs, and development boards. It is a passive adapter and does not perform any signal conditioning or power conversion.
