High accuracy oscilloscope current probe can measure 400A, maximum voltage 600V rms. Bandwidths up to 150KHz. The AC/DC Current Clamp are two current ranges available.
Peak Range: 0.2A to 40A, 40A to 400A.
DC Current Range: 0.4A to 40A, 40A to 400A.
Widely Used: The current probe features BNC interface, compatible with all oscilloscopes. The PT740-1A current clamp is also suitable for power measurements, measure RMS values in the presence of DC interference.
Package Included: PT740-1A AC/DC Current Clamp x 1, Adapter x 1, Manual x 1. 【NOTE】Default delivery to adapter-powered current probe, If you want battery-powered current probe, please contact us! BUT BATTERY NOT INCLUDED.

MODEL: PT740-1A

Bandwidth (-3dB): DC-150kHz

Current Range:
Peak:0.2A~40A, 40A~400A

DC:0.4A~40A, 40A~400A

Out Signal Ratio: 10mV/A(100:1), 1mV/A(1000:1)

Out Signal Inaccuracy(typical):±1.5%+5mV

Noise:1mV rms

Rise/Fall Time:2.3μs

The load impedence:≥1MΩ and ≤100pF

Insert Impedance: 0.39mΩ at 50Hz, 58mΩ at 1000Hz

Working Voltage: Max 600V rms

Common-mode voltage: Max 600V rmsv Influence of Adjacent Conductors:
Influence of Jaw Conductor Position: 0.5% of reading

Battery Capacity Indicator: When >6.5V，the green LED illuminates

Overload Indicator: Red LED is on

Automatic Shutdown Time: 10 minutes

DC Zero Adjustment: Supprot

Jaw Size(insert conductor): 1 cable: 30mm diameter; 2 cables: 24mm diameter or 2×31.5×10mm busbar

Output: Cable length 2M/78.7in, BNC connector

Weight: 440g/0.97lb

Size: 224 x 97 x 44 mm
