The 310 Series is a 3 hour fire-rated, industrial grade electric strike designed for extreme heavy duty applications. The all stainless steel construction of this device makes it ideal for high abuse applications that would disable other electric strikes.
Specifications
UL 10C, 3 hour fire-rated (fail secure only)
CAN4-S104 (ULC-S104) fire door conformant
UL1034, burglary-resistant listed
UL 294 (6th Edition) listed
ANSI/BHMA A156.31, Grade 1
NFPA-252 fire door conformant
ASTM-E152 fire door conformant
Electrical
.51 Amps @ 12VDC continuous duty
.25 Amps @ 24VDC continuous duty
Standard Features
Integrated shim for quick customization of faceplate thickness (1/2" to 3/4")
Tamper resistant, heavy-duty construction
Constructed entirely of stainless steel for strength and corrosion resistance
Static strength 1,500 lbs.
Dynamic strength 70 ft-lbs.
Endurance rating 500,000 cycles
Integrated ramps for better deadlatch handling
Set screws for horizontal lockdown
In-frame horizontal adjustability
Wider faceplate (1-3/4”) for greater versatility
Non-handed
Five year limited warranty
