Introduction
This product adopts piezoelectric effect of artificial po- larized ceramic for design.
It is suitable for monitoring all kinds of vibrating mechanical facility, specially the vibration measurement of rotating and reciprocating machinery.
The unit can measure acceleration, velocity and displacement, which is widely used in mechanical manufacture, electric power metallurgy and general aviation etc.

Specification
Model: WT63A
Vibration pickup: Piezoelectric ceramic accelerometer (shear-type)
Measurement range of acceleration: 0.1~199.9m/s2 peak
Measurement range of velocity: 0.1~199.9mm/s rms
Measurement range of displacement: 0.001~1.999mm p-p Velocity and displacement range is limited by acceleration199.9m/s2
Measurement accuracy: ±5%±2digits
Measurement frequency range of acceleration: 10Hz～1KHz (LO) 1KHz～15KHz (HI)
Measurement frequency range of velocity: 10Hz～1KHz (LO)
Measurement frequency range of displacement: 10Hz～1KHz (LO)
Displays update cycle: 1 second
LCD display: 3 1/2 digits display
Single output: AC output 2 V peak (display full scale); Load impedance 10KΩor more earphones can be connected
Power supply: 9V Alkaline battery
Static current: ≤20μA
Operating current: ≤20μA
Operating current: ≤25mA
Battery life: 20 hours continuous use
Auto power-off: Turns off automatically in 60 seconds
LCD backlight: 7 seconds
Operating temperature range: 0~40℃
Operating humidity range: 30~90%RH
Low battery indication: 6.9V±0.2V
Dimensions: 67x30x183mm
Weight: 182g ( including battery)
