Oil nozzles type OD are designed for domestic and commercial high-pressure oil burners operating with light or heavy fuel. The available Oil furnance nozzle features a 60 degree spray angle, S Solid spray pattern in size of 35.0 USgal/h. As to construction and atomizing, the OD nozzle is the basic model for all Danfoss oil nozzles.

OEM Replacement for Aqua Hot WPX-886-41A (WPX88641A) and FLX-013-150 diesel fuel nozzles

Compatibility:
Used On Aqua Hot Models: AHE-100-00S, AHE-100-01S, AHE-100-02S, AHE-100-03S, AHE-100-04S, AHE-101-000, AHE-120-03X, AHE-120-04X, AHE-130-03X, AHE-130-04X, AHE-375-D02, AHE-375-D03, AHE-450-DE1, AHE-450-DE2, AHE-450-DE3, AHE-525-D02, AHE-600-D01, AHE-600-D02, AHE-600-D03

Used On Hydro Hot Models: HHE-200-07E, HHE-500-07M, HHE-200-08E, HHE-500-08M, HHE-200-09E, HHE-500-09M

Used On Webasto Models: DBW 2010, DBW 2020

Capacity: 1.35 kg/h/0.35 gal/h
Filter grade [µm]: 30
Filter type: Sinter
Specification point: 10 bar, 3.4 cSt, 840 kg/m³
Spray angle: 60 degrees
Spray pattern: Solid
