Fitment:

For 1995 Chevy Blazer 4.3L 262Cu. In. V6 GAS OHV Naturally Aspirated

For 1995 Chevy S10 4.3L 262Cu. In. V6 GAS OHV Naturally Aspirated

For 1995 GMC Jimmy 4.3L 262Cu. In. V6 GAS OHV Naturally Aspirated

For 1994-1995 GMC Sonoma 4.3L 262Cu. In. V6 GAS OHV Naturally Aspirated

OE/OEM Part Number: GM3010228, 52462548, 1553, CU1533

Radiator Size of Shroud Fan:

Core Size: 26 3/10'' W x 14 9/10'' H

Overall Size: 33 1/5'' W x 17 3/5'' H

12'' Fan Specification:

Maximum Fan CFM: 1730 cfm

Fan Diameter: 12.050"

Number of Blades: 10 S-Type blades

Blade Material: Plastic

Includes the Mounting Tabs for an Easy Zip Tie Installation

Thermostat Kit Installation:

Universal fit for any automotive vehicle and electric fan.

Activates by grounding electric fans at preset temperature.

185'F turn-on temperature, 165'F turn-off temperature.

RED + connect directly to battery.

WHITE wire to ignition switch power source.

BLACK goes to thermos switch.

BLUE wire goes to the Fans.

This set up will run Fans & pull air in through radiator.

Package Include:

1 x AA5052 Aluminum Shroud

2 x 12'' Fans (Includes mounting kits)

1 x Thermostat Relay Kit

Features:

- Shuttered design AA5052 fan shroud to guaranteed airflow passes high efficiently.

- S blade fans, Push or Pull Type design,lightweight plastic durable material.

- Additional with thermostat,professional matching advice, consider for every detail and needed.

AA5052 Aluminum Shroud and Fans:

The New Design fan and the AA5052 fan shroud effectively drive the heat over and out the engine compartment rather than thrusting it into the front of the engine.
