Adjusters
Specification
Type
SFR-2000
SFR-3000
SFR-4000
Port Size G
1/4"
3/8"
1/2"
Fluid
Air
Filter Precision
Standard : 20um
Operating Pressure Range MPa
0.15 ~ 0.85
Max. Flow rate L/min
650
1400
Ambient temperature C
-10 ~ 60
Differential Pressure Type
Manual drain standard
Automatic drain option
Adopting Pressure Differential for automatic drain , drain automatically when the air depletion and make up produce differential
Also placed the left to be differential pressure type
Use float switch valve , drain automatically when water level over the float , close automatically after completely drain
Warning:
Confirm the air line and power in turned off before serving , prevent injury and damage while disassembly for maintenance.
Danger :
Pay attention to the direction of the air while installing, never used in reversed air direction .
High-concerned chemical : None
Motivity Type : Other
Type : Treatment Unit
Model Number : SFR2000 3000 4000
Origin :
Model : 2000 3000 4000
Port Size : 1/4 , 3/8 , 1/2
Temperature : -10 ~ 60 C
Fluid : Air
Operating Pressure Range : 0.15 ~ 0.85 Mpa
Material : Aluminium Alloy
Thread : G
