LY2N-J 24VDC DPDT 10A 8-Pin Plug-in Relay, LED/Test Button, Compatible with LY2N-J DC24 / LY2N DC24 / LY2NJ DC24; Socket Compatible with PTF08A-E 8-Pin; 250VAC/125VDC

SAR 79
Brand
Kwaich
Weight
19 g
– 1 +

Special Features

  • Specs + OE/PN equivalents — DPDT (2 Form C) power relay, 10A resistive, 250VAC / 125VDC max switching; 24VDC coil ≈36.9mA, 650Ω; operate/release ≈25ms; plug-in 8-pin; status LED and push-to-test button. Compatible with Omron LY2N-J DC24, LY2N-DC24, LY2NJ-DC24. Cross-reference (verify ratings/pinout): Compatible with IDEC RH2B-ULDC24V; Compatible with Finder 56.32.9.024.0040.
  • Installation & location — Plugs into 8-pin octal-style sockets; panel or DIN-rail via socket. Compatible with Omron PTF08A-E 8-pin socket; also Compatible with IDEC RH2B series bases (such as SH2B-05C) when pinout and ratings match. Use a hold-down clip in vibration areas; the LED indicates coil energization (not contact state). DC coil models have no polarity unless a diode option is specified. Use push-to-test strictly for circuit tests.
  • Application fit (industrial) — Suited for machine interlocks, contactor logic, pump/fan control, HVAC and building automation I/O, and light motor loads within rating. Widely used in control cabinets and laser/CNC systems; choose this when you need a compact DPDT 10A plug-in relay with visual coil indication and a test button for commissioning.
  • Replacement guidance — To replace an existing relay, match: (a) coil voltage 24VDC, (b) contact form DPDT, (c) contact rating 10A and switching voltage, (d) 8-pin plug-in footprint, and (e) socket compatibility (e.g., PTF08A-E). For brand-to-brand swaps, confirm via official cross-reference/tools and datasheets before use
  • What issues it solves — Replaces failed panel relays that cause no output or intermittent chattering in control circuits; lets technicians confirm coil energization at a glance (LED) and momentarily test circuits (push-to-test) during commissioning. Remember: the indicator shows coil power only; verify actual contact operation in your circuit
  • Complementary items for a clean install — Compatible with Omron PTF08A-E 8-pin socket (front mounting), optional hold-down/retainer clips for vibration, and DIN-rail adapter/socket bases in the same family. Stocking spare sockets reduces downtime during panel service.

Description

LY2N-J 24VDC DPDT 10A 8-Pin Plug-In Relay (with LED & Test Button)This general-purpose, plug-in power relay delivers dependable switching for industrial control panels, HVAC equipment, and machinery I/O where a compact DPDT (2 Form C) contact set and visual coil indication are required.
Contact Form: DPDT (2 Form C), plug-in 8-pin
Contact Rating: 10A resistive (see datasheet for inductive ratings)
Max Switching Voltage: 250VAC / 125VDC
Coil: 24VDC, ~36.9 mA, ~650 Ω
Operate/Release Time: ~25 ms / ~25 ms
Features: Operation LED indicator; push-to-test button
Typical Use: Panel I/O, motor/pump/fan control, interlocks, automation
Compatible with Omron LY2N-J DC24, LY2N-DC24, LY2NJ-DC24; and, where ratings/pinout match, Compatible with IDEC RH2B-ULDC24V and Compatible with Finder 56.32.9.024.0040.
Socket Mounting: Fits Compatible with Omron PTF08A-E 8-pin socket and other 8-pin octal-style bases with the same pin layout.
Mounting Options: Panel or DIN-rail via the chosen socket; use a retainer/clip in high-vibration locations.
Indicator/Test: LED shows coil energization; the test button is for momentary circuit testing only.
Polarity: DC coil type has no polarity unless a diode option is used. Always follow the wiring diagram on the relay/base.
No output from control circuits due to failed relay contacts or non-energizing coil
Intermittent operation/chattering in panels where a reliable DPDT 10A plug-in relay is required
Always verify coil voltage, contact form/rating, and socket pinout before replacement. Use within the published electrical ratings.
