Valves
DN25 technical parameters
Working pressure: 0.03-1MPa
Ideal working pressure: 0.1-0.5MPa
Cold water temperature: 5-29oC, hot water temperature: 50-99oC
Range of temperature regulation: 35-45oC (50-60oC)
Temperature control accuracy: + 2oC, outlet flow: 2.9m3/h (pressure difference 0.1MPa)
Path: DN 25 (internal thread connection)
==========
High-concerned chemical : None
Structure : Ball
Material : Brass
Temperature of Media : Normal Temperature
Power : Manual
Standard or Nonstandard : Standard
Pressure : Low Pressure
Power Source : AC
Is Smart Device : No
