Select single-phase 120/240VAC detection voltage with jumper copper
Select 50/60Hz with jumper copper
Lost detection voltage protection circuit
Low frequency protection (UFRO) and slow voltage build function
with low frequency indication
Description
Size: 22*17*5 (cm)
Weight: 0.6kg
Technical Parameters
Detection input: Voltage 190-264VAC Two-phase or three-phase
Power input: voltage 170-220VAC three-phase three-wire
Magnetic field output: voltage maximum 120VDC, current continuous 3.7A, non-continuous 10 seconds 6A
Pressure regulation accuracy:
