Air Conditioning System
Model: E-404-000
Cool Only
Coil: 32 pass 4way all aluminum
Expansion valve capacity: 1.
5 Ton
Controls: Thermostat and rotative 3-speed blower switch
Blower motor: 12 VOLTS DOUBLE SHALF
Cooling capacity: 13700BTU
Airflow: 359 CFM
Compressor
Model: C5H142A12V SD508 5H14
Type: Sanden Style 2A Groove Pulley 12v coil
Optional pulley: 8PK
Condenser
Model: CPF142018
Technology: PARALLEL FLOW (tube technology)
Dimensions: 14"H X 20"L X 0.
70"(18mm)W
Material: 4 Rails Aluminum
Connections: #8 IN #6 OUT
Hoses Set
Model: H6516, H81332, H1012
Specifications:
#6 5/16 6 feet
#8 13/32 4 feet
#10 1/2 5 feet
Fitting Set
Model: FTSET404
Contents:
1-N° 10 90° Fitting w/R134a Serv Port
1-N° 8 90° Fitting w/R134a Serv Port
1-N° 10 Straight Fitting
1-N° 10 90° Fitting
2-N° 6 90° Fitting
1-N° 8 90° Fitting
2-N° 6 Straight Fitting
Included accessories: metal FERRULES and CLAMPS
Filter Drier
Model: FD100A ALUMINUM
Model: FD100B BLACK
Dimensions: 2½"Diameter 7½"Height
Features: Sight Glass
Connections: #6 ⅜ X ⅜ both sides
Included components: HI/LOW BINARY PRESSURE SWITCH AND HARNESS CONNECTOR
Condenser Fan
Model: CF1212
Diameter: 12"
Electrical: 12 Volts 80W 6 AMP
: Reversible Puller or Pusher
Included: 4 Mounting Brackets
Compatibility Note:
Refer to OE number for proper fitment verification.
Confirm OEM part number matches your requirements.
for compatibility questions.
