high rigidity, high efficiency (single stage at 97-98%), high torsion /volume ratio, etc.
Most are mounted on stepper and servo motors to reduce RPM, increase torsion, and match inertia.
Sturdy, long life, fit for a variety of environment.
Stable performance, good consistency, low noise, high torsion.
Good abrasion resistance, high ature resistance, shock resistance.
Specification
Condition: Brand New
Item Type: Reduction Motor
Material: Metal
Optional Type: One Stage, Two Stage, Three Stage, Four Stage
6mm One Stage Reduction Motor ParametersFeatures:
Rated Voltage: 3.0V DC
Start Voltage: ≤1DVC
No-Load Current: 50MA
Blocking Current: ≤230MA
Output RPM: 6420±120RPM
Torsion Used: 5g.cm
Ratio: 5.14:1
No-Load Noise: 6mm Two Stage Reduction Motor ParametersFeatures:
Rated Voltage: 3.0V DC
Start Voltage: ≤1DVC
No-Load Current: 50MA
Blocking Current: ≤230MA
Output RPM: 1200±120RPM
Torsion Used: 27g.cm
Ratio: 26.45
No-Load Noise: 6mm Three Stage Reduction Motor ParametersFeatures:
Rated Voltage: 3.0V DC
Start Voltage: ≤1DVC
No-Load Current: 230MA maximum
Blocking Current: ≤200MA
Output RPM: 242±120RPM
Torsion Used: 120g.cm
Ratio: 136.02
No-Load Noise: 6mm Four Stage Reduction Motor ParametersFeatures:
Rated Voltage: 3.0V DC
Start Voltage: ≤0.5DVC
No-Load Current: 200MA maximum
Blocking Current: ≤200MA
Output RPM: 46±5RPM
Torsion Used: 180g.cm
Ratio: 699.5
No-Load Noise: How to Use
Package List
1 x Reduction Motor
