This high-head submersible effluent pump is designed for STEP (Septic Tank Effluent Pumping) systems, mound systems, liquid waste transfer and higher head de-watering applications. This pump is capable of passing up to 3/4" solids. Built of heavy cast iron with an epoxy powder coat finish and stainless steel fasteners, the FL100 will provide years of reliable performance.

Features
Heavy cast iron construction
2 vane semi-open cast iron impeller
416 stainless steel rotor shaft
Dual shaft seals
Single float, mercury free level control
Additional mounting clamp provided for optional switch mounting to pipe
Fully adjustable pumping range
2" FNPT threaded discharge with 1-1/2" FNPT flange provided
Quick-disconnect power cord
3 year warranty
Control Panel Options
Below are Liberty control panels that can be used with this pump.
SX34=3-191
AE34=3-191AE34=4-191
IPS-34-191
IPD-34-191
Specifications:

Brand: Liberty
Mfg. Number: FL103M-2
Application: Effluent / dewatering
Series: FL100
Horsepower: 1 HP
Product Type: Submersible effluent pump
Voltage: 208-230 Volts
Phase: 3
Frequency: 60 Hz
Speed: 3450 RPM
Operation: Manual
Discharge Connection: 2" NPT With 1-1/2" NPT flange
Maximum Flow: 106 GPM
Maximum Total Head: 90 ft
Maximum Solids Handling: 3/4"
Pump Casing Material: Cast iron
Impeller Material: Cast iron
Motor Design: Oil filled
Motor Insulation: Class B
Overload Protection: Must be provided in control panel
Maximum Current: 9 Amps
Maximum Liquid Temperature: 140°F
Power Cord Length: 25 ft
