c i5-4460 specifications
General information
Type
CPU / Microprocessor
Market segment
Desktop
Family
CPU part numbers
CM8064601560722 is an OEM/tray microprocessor
BX80646I54460 is a boxed processor with fan and heatsink (English version)
BXC80646I54460 is a boxed processor with fan and heatsink (Chinese version)
Frequency ?
3200 MHz
Maximum turbo frequency
3200 MHz (4 cores)
3300 MHz (3 cores)
3400 MHz (1 or 2 cores)
Clock multiplier ?
32
Socket 1150 / H3 / LGA1150
S-spec numbers
Architecture / Microarchitecture
Microarchitecture
Haswell
Processor c ?
Haswell
c stepping ?
C0 (QF4J, SR1QK)
Manufacturing process
0.022 micron
Data width
64 bit
The number of CPU cores
4
The number of threads
4
Floating Point Unit
Integrated
Level 1 cache size ?
4 x 32 KB 8-way set associative instruction caches
4 x 32 KB 8-way set associative data caches
Level 2 cache size ?
4 x 256 KB 8-way set associative caches
Level 3 cache size
6 MB 12-way set associative shared cache
Physical memory
32 GB
Multiprocessing
Uniprocessor
Extensions and Technologies
MMX instructions
SSE / Streaming SIMD Extensions
SSE2 / Streaming SIMD Extensions 2
SSE3 / Streaming SIMD Extensions 3
SSSE3 / Supplemental Streaming SIMD Extensions 3
SSE4 / SSE4.1 + SSE4.2 / Streaming SIMD Extensions 4 ?
AES / Advanced Encryption Standard instructions
AVX / Advanced Vector Extensions
AVX2 / Advanced Vector Extensions 2.0
BMI / BMI1 + BMI2 / Bit Manipulation instructions
F16C / 16-bit Floating-Point conversion instructions
FMA3 / 3-operand Fused Multiply-Add instructions
NX / XD / Execute disable bit ?
TBT 2.0 / Turbo Boost technology 2.0 ?
VT-x / Virtualization technology ?
VT-d / Virtualization for directed I/O
Low power features
Enhanced / technology ?
Integrated peripherals / components
Integrated graphics
GPU Type: HD 4600
Graphics tier: GT2
Microarchitecture: Gen 7.5
Execution units: 20
Base frequency (MHz): 350
Maximum frequency (MHz): 1100
The number of supported displays: 3
Memory controller
The number of controllers: 1
Memory channels: 2
Supported memory: DDR3-1333, DDR3-1600
Maximum memory bandwidth (GB/s): 25.6
Other peripherals
Direct Media Interface 2.0
PCI Express 3.0 interface
Electrical / Thermal parameters
Maximum operating temperature ?
72.72°C
Thermal Design Power ?
84 Watt
Notes on c i5-4460
The processor has the following security, data protection and/or software features: Secure Key, Identity Protection technology, OS Guard and Anti-Theft technology.
The CPU is compatible with DirectX 11.2, OpenGL 4.3 and OpenCL 1.2 APIs.
The graphics unit has the following software features enabled: Wireless Display, Quick Sync Video, Clear Video HD technology, InTru 3D technology and Insider.
