ph II X6 1100T specifications
General information
Type
CPU / Microprocessor
Market segment
Desktop
Family
CPU part numbers
HDE00ZFBK6DGR is an OEM/tray microprocessor
HDE00ZFBGRBOX is a boxed microprocessor with fan and heatsink
Stepping codes
ACBBE CBCCBBE CB
Frequency?
3300 MHz
Turbo frequency
3700 MHz (3 cores or less)
Bus speed?
667 MHz Memory controller
One 2000 MHz 16-bit HyperTransport link (4 GT/s)
Clock multiplier?
16.5
Socket AM3
Weight
1.4oz / 38.4g (CPU)
Architecture / Microarchitecture
Microarchitecture
K10
Platform
Leo
Processor c ?
Thuban
c stepping ?
PH-E0
CPUID
100FA0
Manufacturing process
0.045 micron silicon-on-insulator (SOI) technology
Die
346mm2
Data width
64 bit
The number of CPU cores
6
The number of threads
6
Floating Point Unit
Integrated
Level 1 cache size ?
6 x 64 KB 2-way set associative instruction caches
6 x 64 KB 2-way set associative data caches
Level 2 cache size?
6 x 512 KB 16-way set associative exclusive caches
Level 3 cache size
Shared 6 MB 48-way set associative cache
Cache latency
3 (L1 cache)
Multiprocessing
Uniprocessor
Features
MMX instructions
Extensions to MMX
3DNow! technology
Extensions to 3DNow!
SSE / Streaming SIMD Extensions
SSE2 / Streaming SIMD Extensions 2
SSE3 / Streaming SIMD Extensions 3
SSE4a ?
Turbo c technology
Low power features
Cool'n'Quiet 3.0
c C1 and C1E states
Package S0, S1, S3, S4 and S5 states
Integrated peripherals / components
Integrated graphics
None
Memory controller
The number of controllers: 1
Memory channels: 2
Channel width (bits): 72
Supported memory: DDR2-1066, DDR3-1333
DIMMs per channel: up to 2
Maximum memory bandwidth (GB/s): 21.3
Other peripherals
HyperTransport 3 technology
Electrical / Thermal parameters
V c ?
1V - 1.475V
Maximum operating temperature ?
62°C
Thermal Design Power?
125 Watt
Notes on ph II X6 1100T
The processor has unlocked clock multiplier
