12th Generation c i5 Processors
Processor Number
i5-12400
CPU Specifications
Total Cores
6# of Performance-cores
6# of Efficient-cores
0Total Threads
12
Max Turbo Frequency
4.40 GHz
Performance-core Max Turbo Frequency
4.40 GHz
Performance-core Base Frequency
2.50 GHz
Cache
Total L2 Cache
7.5 MB
Processor Base Power
65 W
Maximum Turbo Power
117 W
Supplemental Information
Embedded Options Available
Yes
Datasheet
View now
Memory Specifications
Max Memory Size (dependent on memory type)
128 GB
Memory Types
Up to DDR5 4800 MT/s
Up to DDR4 3200 MT/s
Max # of Memory Channels
2Max Memory Bandwidth
76.8 GB/s
Processor Graphics
Graphics Base Frequency
300 MHz
Graphics Output
eDP 1.4b, DP 1.4a, HDMI 2.1
Execution Units
24
Max Resolution (HDMI)
4096 x 2160 @ 60Hz
Max Resolution (DP)
7680 x 4320 @ 60Hz
Max Resolution (eDP - Integrated Flat Panel)
5120 x 3200 @ 120Hz
DirectX* Support
12
OpenGL* Support
4.5
Multi-Format Codec Engines plays Supported
4Device ID
0x4692 / 0x4682
OpenCL* Support
2.1
Expansion Options
Direct Media Interface (DMI) Revision
4.0
Max # of DMI Lanes
8Scalability
1S Only
PCI Express Revision
5.0 and 4.0
PCI Express Configurations
Up to 1x16+4, 2x8+4
Max # of PCI Express Lanes
20
Specifications
Sockets Supported
FCLGA1700
Max CPU Configuration
1Thermal Solution Specification
PCG 2020C
TJUNCTION
100°C
