ph II X2 B55 specifications
General information
Type
CPU / Microprocessor
Market segment
Desktop
Family
CPU part number
HDXB55WFK2DGM is an OEM/tray microprocessor
Stepping codes
CACAC ACCACDC AC
Frequency ?
3000 MHz
Bus speed ?
533 MHz Memory controller
One 2200 MHz 16-bit HyperTransport link (4.4 GT/s)
Clock multiplier ?
15
Socket AM2+
Socket AM3
Architecture / Microarchitecture
Microarchitecture
K10
Platform
Dragon
Processor c ?
Callisto
c stepping ?
RB-C3
CPUID
100F43
Manufacturing process
0.045 micron silicon-on-insulator (SOI) technology
Die
258mm2
Data width
64 bit
The number of CPU cores
2
The number of threads
2
Floating Point Unit
Integrated
Level 1 cache size ?
2 x 64 KB 2-way set associative instruction caches
2 x 64 KB 2-way set associative data caches
Level 2 cache size ?
2 x 512 KB 16-way set associative exclusive caches
Level 3 cache size
Shared 6 MB 48-way set associative cache
Cache latency
3 (L1 cache)
Multiprocessing
Uniprocessor
Features
MMX instructions
Extensions to MMX
3DNow! technology
Extensions to 3DNow!
SSE / Streaming SIMD Extensions
SSE2 / Streaming SIMD Extensions 2
SSE3 / Streaming SIMD Extensions 3
SSE4a ?
Low power features
Cool'n'Quiet 3.0
CoolCore Technology ?
Dual Dynamic Power Management ?
c C1 and C1E states
Package S0, S1, S3, S4 and S5 states
Integrated peripherals / components
Integrated graphics
None
Memory controller
The number of controllers: 1
Memory channels: 2
Channel width (bits): 72
Supported memory: DDR2-1066, DDR3-1066
DIMMs per channel: 2
Maximum memory bandwidth (GB/s): 17.1
Other peripherals
HyperTransport 3 technology
Electrical / Thermal parameters
V c ?
0.775V - 1.425V
Maximum operating temperature ?
55°C - 70°C
Thermal Design Power ?
80 Watt
Notes on ph II X2 B55
Business class processor
The fastest supported memory is DDR2-1066
