c i7-2920XM specifications
General information
Type
CPU / Microprocessor
Market segment
Mobile
Family
CPU part number
FF8062700834406 is an OEM/tray microprocessor
Frequency ?
2500 MHz
Maximum turbo frequency
3500 MHz (1 c)
3400 MHz (2 cores)
3200 MHz (3 or 4 cores)
Clock multiplier ?
25
Socket G2 / rPGA988B
S-spec numbers
Architecture / Microarchitecture
Microarchitecture
Sandy Bridge
Processor c ?
Sandy Bridge
c stepping ?
D2 (SR02E)
CPUID
206A7 (SR02E)
Manufacturing process
0.032 micron High-K metal gate process
Data width
64 bit
The number of CPU cores
4
The number of threads
8
Floating Point Unit
Integrated
Level 1 cache size ?
4 x 32 KB 8-way set associative instruction caches
4 x 32 KB 8-way set associative data caches
Level 2 cache size ?
4 x 256 KB 8-way set associative caches
Level 3 cache size
8 MB 16-way set associative shared cache
Physical memory
8 GB
Multiprocessing
Not supported
Extensions and Technologies
MMX instructions
SSE / Streaming SIMD Extensions
SSE2 / Streaming SIMD Extensions 2
SSE3 / Streaming SIMD Extensions 3
SSSE3 / Supplemental Streaming SIMD Extensions 3
SSE4 / SSE4.1 + SSE4.2 / Streaming SIMD Extensions 4 ?
AES / Advanced Encryption Standard instructions
AVX / Advanced Vector Extensions
HT / Hyper-Threading technology ?
VT-x / Virtualization technology ?
VT-d / Virtualization for directed I/O
TBT 2.0 / Turbo Boost technology 2.0 ?
Security Features
NX / XD / Execute disable bit ?
TXT / Trusted Execution technology
Low power features
Enhanced / technology ?
Integrated peripherals / components
Integrated graphics
GPU Type: HD 3000
Microarchitecture: Gen 6
Execution units: 12
Base frequency (MHz): 650
Maximum frequency (MHz): 1300
The number of supported displays: 2
Memory controller
The number of controllers: 1
Memory channels (per controller): 2
Memory channels (total): 2
Supported memory: DDR3-1066, DDR3-1333, DDR3-1600
Maximum memory bandwidth (GB/s): 25.6
Other peripherals
Direct Media Interface 2.0
PCI Express 2.0 interface
Electrical / Thermal parameters
Maximum operating temperature ?
100°C
Thermal Design Power ?
55 Watt
Notes on c i7-2920XM
The processor has unlocked clock multiplier
The processor has the following security, data protection and/or software features: vPro technology, Identity Protection technology and technology.
The CPU is compatible with Shader Model 4.1, along with DirectX 10.1 and OpenGL 3.1 APIs. OpenCL API is not supported.
The graphics unit has the following software features enabled: Quick Sync Video, Wireless Display, Insider, InTru 3D technology and Clear Video HD technology.
