Type
CPU / Microprocessor
Market segment
Desktop
Family
ph II X4
Model number ?
960T
CPU part numbers
HD96ZTWFK4DGR is an OEM/tray microprocessor
HD96ZTWFGRBOX is a boxed microprocessor with fan and heatsink
Stepping codes
ACBBE CBCCBBE CB
Frequency ?
3000 MHz
Turbo frequency
3400 MHz
Bus speed ?
2000 MHz HyperTransport link (4 GT/s)
Clock multiplier ?
15
Package
938-pin organic micro-PGA
Sockets
Socket AM2+
Socket AM3
Weight
1.3oz / 38g
Architecture / Microarchitecture
Microarchitecture
K10
Platform
Leo
Processor c ?
Zosma
c stepping ?
PH-E0
CPUID
100FA0
Manufacturing process
0.045 micron silicon-on-insulator (SOI) technology
Die
346mm2
Data width
64 bit
The number of CPU cores
4
The number of threads
4
Floating Point Unit
Integrated
Level 1 cache size ?
4 x 64 KB 2-way set associative instruction caches
4 x 64 KB 2-way set associative data caches
Level 2 cache size ?
4 x 512 KB 16-way set associative exclusive caches
Level 3 cache size
Shared 6 MB 48-way set associative cache
Cache latency [1]
3 (L1 cache)
14 (L2 cache)
51 (L3 cache)
Multiprocessing
Uniprocessor
Features
MMX instructions
Extensions to MMX
3DNow! technology
Extensions to 3DNow!
SSE / Streaming SIMD Extensions
SSE2 / Streaming SIMD Extensions 2
SSE3 / Streaming SIMD Extensions 3
SSE4a ?
Turbo c technology
Low power features
Cool'n'Quiet 3.0
c C1 and C1E states
Package S0, S1, S3, S4 and S5 states
Integrated peripherals / components
Integrated graphics
None
Memory controller
The number of controllers: 1
Memory channels: 2
Channel width (bits): 72
Supported memory: DDR2-1066, DDR3-1333
DIMMs per channel: up to 2
Maximum memory bandwidth (GB/s): 21.3
Other peripherals
HyperTransport 3 technology
Electrical / Thermal parameters
V c ?
0.825V - 1.4V
Thermal Design Power ?
95 Watt
