Type
CPU / Microprocessor
Market segment
Desktop
Family
A10-Series
Model number?
A10-6700
CPU part numbers
AD6700OKA44HLis an OEM/tray microprocessor
AD6700OKHLBOXis a boxed microprocessor with fan and heatsink
Frequency?
3700 MHz
Turbo frequency
4300 MHz
Boosted P states[1]
#1: 4300 MHz, 1.325V
#2: 4200 MHz, 1.275V
#3: 3900 MHz, 1.05V
Package
904-pin organic lidded micro Pin Grid Array (UOF904)
Socket
Socket FM2
Size
1.57" x 1.57" / 4cm x 4cm
Weight
1.4oz / 39g
Architecture / Microarchitecture
Microarchitecture
Piledriver
Processor c?
Richland
c stepping?
RL-A1
CPUID
610F31
Manufacturing process
0.032 micron
1.3 billion transistors
Data width
64 bit
The number of CPU cores
4
The number of threads
4
Floating Point Unit
Integrated (shared between two cores in each module)
Level 1 cache size?
2 x 64 KB 2-way set associative shared instruction caches
4 x 16 KB 4-way set associative data caches
Level 2 cache size?
2 x 2 MB 16-way set associative shared exclusive caches
Level 3 cache size
None
Cache latency
3 (L1 cache)
Multiprocessing
Uniprocessor
Features
MMX instructions
Extensions to MMX
SSE / Streaming SIMD Extensions
SSE2 / Streaming SIMD Extensions 2
SSE3 / Streaming SIMD Extensions 3
SSSE3 / Supplemental Streaming SIMD Extensions 3
SSE4 / SSE4.1 + SSE4.2 / Streaming SIMD Extensions 4?
SSE4a?
AES / Advanced Encryption Standard instructions
AVX / Advanced Vector Extensions
BMI1 / Bit Manipulation instructions 1
F16C / 16-bit Floating-Point conversion instructions
FMA3 / 3-operand Fused Multiply-Add instructions
FMA4 / 4-operand Fused Multiply-Add instructions
TBM / Trailing Bit Manipulation instructions
XOP / eXtended Operations instructions
AMD64 / A 64-bit technology?
AMD-V / A Virtualization technology
EVP / Enhanced a Protection?
Turbo c 3.0 technology
Low power features
c C1, C1E, C6 and CC6 states
Package S3, S4 and S5 states
PowerNow!
Low power P states[1]
#1: 3400 MHz, 0.8V
#2: 2700 MHz, 0.675V
#3: 2300 MHz, 0.45V
#4: 1800 MHz, 0.2V
Integrated peripherals / components
Integrated graphics
GPU Type: Radeon HD 8670D
Shader cores: 384
Base frequency (MHz): 844
Memory controller
The number of controllers: 1
Memory channels: 2
Supported memory: DDR3-1866
Maximum memory bandwidth (GB/s): 29.9
Other peripherals
PCI Express 2.0
Unified Video Decoder 3.2?
Electrical / Thermal parameters
Maximum operating temperature?
71.3°C
Thermal Design Power?
65 Watt
