Type
CPU / Microprocessor
Market segment
Desktop
Family
R 5
Model number ?
1500X
CPU part numbers
YD150XBBM4GAE is an OEM/tray microprocessor
YD150XBBAEBOX is a boxed microprocessor with fan and heatsink
Frequency ?
3500 MHz
Maximum turbo frequency
3700 MHz
Package
1331-pin lidded micro-PGA package
Socket
Socket AM4
Architecture / Microarchitecture
Microarchitecture
Zen
Processor c ?
Summit Ridge
c stepping ?
ZP-B1
CPUID
800F11
Manufacturing process
0.014 micron FinFET process
4.8 billion transistors
Data width
64 bit
The number of CPU cores
4
The number of threads
8
Floating Point Unit
Integrated
Level 1 cache size ?
4 x 64 KB 4-way set associative instruction caches
4 x 32 KB 8-way set associative data caches
Level 2 cache size ?
4 x 512 KB inclusive 8-way set associative unified caches
Level 3 cache size
2 x 8 MB exclusive 16-way set associative shared caches
Multiprocessing
Uniprocessor
Extensions and Technologies
MMX instructions
Extensions to MMX
SSE / Streaming SIMD Extensions
SSE2 / Streaming SIMD Extensions 2
SSE3 / Streaming SIMD Extensions 3
SSSE3 / Supplemental Streaming SIMD Extensions 3
SSE4 / SSE4.1 + SSE4.2 / Streaming SIMD Extensions 4 ?
SSE4a ?
AES / Advanced Encryption Standard instructions
AVX / Advanced Vector Extensions
AVX2 / Advanced Vector Extensions 2.0
BMI / BMI1 + BMI2 / Bit Manipulation instructions
F16C / 16-bit Floating-Point conversion instructions
FMA3 / 3-operand Fused Multiply-Add instructions
SHA / Secure Hash Algorithm extensions
Precision Boost
Extended Frequency Range
Security Features
EVP / Enhanced a Protection ?
SMAP / Supervisor Mode Access Prevention
SMEP / Secure Mode Execution Protection
Low power features
Pure Power
Integrated peripherals / components
Integrated graphics
None
Memory controller
The number of controllers: 2
Memory channels per controller: 1
Channel width (bits): 64
Supported memory: DDR4-2666 [1]
DIMMs per channel: 2
Maximum memory bandwidth (GB/s): 42.7 [1]
Other peripherals
PCI Express 3.0 interface (16 lanes)
Electrical / Thermal parameters
Maximum operating temperature ?
95°C
Thermal Design Power ?
65 Watt
