Type
CPU / Microprocessor
Market segment
Mobile
Family
A8-Series for Notebooks
Model number?
A8-4500M
CPU part number
AM4500DEC44HJis an OEM/tray microprocessor
Frequency?
1900 MHz
Maximum turbo frequency
2800 MHz
Boosted P states[1]
#1: 2800 MHz, 0.925V
#2: 2300 MHz, 0.7V
Package
722-pin organic lidless micro Pin Grid Array (UOL722)
Socket
Socket FS1 (FS1r2)
Size
1.38" x 1.38" / 3.5cm x 3.5cm
Weight
0.2oz / 6g
Architecture / Microarchitecture
Microarchitecture
Piledriver
Platform
Comal
Processor c?
Trinity
c stepping?
TN-A1
CPUID
610F01
Manufacturing process
0.032 micron
1303 million transistors
Die
246mm2
Data width
64 bit
The number of CPU cores
4
The number of threads
4
Floating Point Unit
Integrated (shared between two cores in each module)
Level 1 cache size?
2 x 64 KB 2-way set associative shared instruction caches
4 x 16 KB 4-way set associative data caches
Level 2 cache size?
2 x 2 MB 16-way set associative shared exclusive caches
Level 3 cache size
None
Cache latency
3 (L1 cache)
Multiprocessing
Uniprocessor
Features
MMX instructions
Extensions to MMX
SSE / Streaming SIMD Extensions
SSE2 / Streaming SIMD Extensions 2
SSE3 / Streaming SIMD Extensions 3
SSSE3 / Supplemental Streaming SIMD Extensions 3
SSE4 / SSE4.1 + SSE4.2 / Streaming SIMD Extensions 4?
SSE4a?
AES / Advanced Encryption Standard instructions
AVX / Advanced Vector Extensions
BMI1 / Bit Manipulation instructions 1
F16C / 16-bit Floating-Point conversion instructions
FMA3 / 3-operand Fused Multiply-Add instructions
FMA4 / 4-operand Fused Multiply-Add instructions
TBM / Trailing Bit Manipulation instructions
XOP / eXtended Operations instructions
EVP / Enhanced a Protection?
Turbo c 3.0 technology
Low power features
c C1, C1E, C6 and CC6 states
Package S3, S4 and S5 states
PowerNow!
Low power P states[1]
#1: 1800 MHz, 0.375V
#2: 1700 MHz, 0.275V
#3: 1600 MHz, 0.225V
#4: 1400 MHz, 0.175V
#5: 900 MHz, 0.175V
Integrated peripherals / components
Integrated graphics
GPU Type: Radeon HD 7640G
Shader cores: 256
Base frequency (MHz): 496
Maximum frequency (MHz): 685
Memory controller
The number of controllers: 1
Memory channels: 2
Supported memory: DDR3-1600, DDR3L-1600, DDR3U-1333
Maximum memory bandwidth (GB/s): 25.6
Other peripherals
PCI Express 2.0
Unified Video Decoder 3.2?
DVI / DisplayPort / HDMI / VGA display controllers
Electrical / Thermal parameters
V c?
0.8125V - 1.3V
Maximum operating temperature?
100°C
Thermal Design Power?
35 Watt
