General information
Type CPU / Microprocessor
Market segment Desktop
Family A 64 X2
Model number ? 6000+
CPU part numbers ADX6000IAA6CZ is an OEM/tray microprocessor
ADX6000CZBOX is a boxed microprocessor with fan and heatsink
Stepping codes ACB9F ACBVF CCB6F CCB8F CCBVF
Frequency ? 6000+ (rated)
3000 MHz (real)
Bus speed ? One 1000 MHz 16-bit HyperTransport link (2GT/s)
Clock multiplier ? 15
Package 940-pin organic micro Pin Grid Array (micro-PGA)
Socket Socket AM2
Architecture / Microarchitecture
Microarchitecture K8
c stepping ? JH-F3
CPUID 40F33
Manufacturing process 0.09 micron silicon-on-insulator (SOI) technology
243 million transistors
Data width 64 bit
The number of CPU cores 2
The number of threads 2
Floating Point Unit Integrated
Level 1 cache size ? 2 x 64 KB 2-way set associative instruction caches
2 x 64 KB 2-way set associative data caches
Level 2 cache size ? 2 x 1 MB 16-way set associative exclusive caches
Physical memory 1 TB
Virtual memory 256 TB
Multiprocessing Uniprocessor
Extensions and Technologies MMX instructions
Extensions to MMX
3DNow! technology
Extensions to 3DNow!
SSE / Streaming SIMD Extensions
SSE2 / Streaming SIMD Extensions 2
SSE3 / Streaming SIMD Extensions 3
Low power features Cool'n'Quiet technology
Halt state
Stop Grant state ?
Integrated peripherals / components
Integrated graphics None
Memory controller The number of controllers: 1
Memory channels: 2
Supported memory: DDR2-800
Maximum memory bandwidth (GB/s): 12.8
Other peripherals HyperTransport 2.0 technology (1 link)
Electrical / Thermal parameters
V c ? 1.35V / 1.4V
Maximum operating temperature ? 55°C - 63°C
Thermal Design Power ? 125 Watt
