c i5-9600KF specifications
The specs can be used for short-term
General information
Type
CPU / Microprocessor
Market segment
Desktop
Family
Model number ?
i5-9600KF
CPU part numbers
CM8068403874409 is an OEM/tray microprocessor
CM8068403874410 is an OEM/tray microprocessor
BX80684I59600KF is a boxed processor (English version)
BXC80684I5960KF is a boxed processor (Chinese version)
Frequency ?
3700 MHz
Maximum turbo frequency
4600 MHz
Low power frequency
800 MHz
Bus speed ?
8 GT/s
Clock multiplier ?
37
Package
1151-land Flip-Chip Land Grid Array
S-spec numbers
Part number
Production processors
SRFAD
SRG12
BX80684I59600KF
+
BXC80684I5960KF
+
CM8068403874409
+
CM8068403874410
+
Architecture / Microarchitecture
Microarchitecture
Coffee Lake
Processor c ?
Coffee Lake-S
c steppings ?
P0 (SRFAD)
R0 (SRG12)
Manufacturing process
0.014 micron
Data width
64 bit
The number of CPU cores
6
The number of threads
6
Floating Point Unit
Integrated
Level 1 cache size ?
6 x 32 KB 8-way set associative instruction caches
6 x 32 KB 8-way set associative data caches
Level 2 cache size ?
6 x 256 KB 4-way set associative caches
Level 3 cache size
9 MB 12-way set associative shared cache
Physical memory
128 GB
Multiprocessing
Uniprocessor
Extensions and Technologies
MMX instructions
SSE / Streaming SIMD Extensions
SSE2 / Streaming SIMD Extensions 2
SSE3 / Streaming SIMD Extensions 3
SSSE3 / Supplemental Streaming SIMD Extensions 3
SSE4 / SSE4.1 + SSE4.2 / Streaming SIMD Extensions 4 ?
AES / Advanced Encryption Standard instructions
AVX / Advanced Vector Extensions
AVX2 / Advanced Vector Extensions 2.0
BMI / BMI1 + BMI2 / Bit Manipulation instructions
F16C / 16-bit Floating-Point conversion instructions
FMA3 / 3-operand Fused Multiply-Add instructions
EM64T / Extended Memory 64 technology / I 64 ?
VT-x / Virtualization technology ?
VT-d / Virtualization for directed I/O
TBT 2.0 / Turbo Boost technology 2.0 ?
TSX / Transactional Synchronization Extensions
Security Features
NX / XD / Execute disable bit ?
MPX / Memory Protection Extensions
SGX / Software Guard Extensions
SMAP / Supervisor Mode Access Prevention
SMEP / Secure Mode Execution Protection
Low power features
c C1/C1E, C3, C6, C7, C8, C9 and C10 states
Package C2, C3, C6, C7, C8, C9 and C10 states
Enhanced / technology ?
Integrated peripherals / components
Integrated graphics
None
Memory controller
The number of controllers: 1
Memory channels: 2
Channel width (bits): 64
Supported memory: DDR4-2666
DIMMs per channel: 2
Maximum memory bandwidth (GB/s): 42.7
Other peripherals
Direct Media Interface 3.0 (4 lanes)
PCI Express 3.0 interface (16 lanes)
Electrical / Thermal parameters
Minimum/Maximum operating temperature ?
0°C (case temperature) - 65°C (case temperature) [1]
100°C (Digital Thermal Sensor)
Thermal Design Power ?
95 Watt
Notes on c i5-9600KF
The processor has unlocked clock multiplier
Optane memory is supported
Package C10 low power state is not supported on 200 series chipsets
The processor has the following security, data protection and/or software features: I Secure Key, Identity Protection technology, OS Guard and Boot Guard.
[1] - Information is not confirmed
