General information
Type
CPU / Microprocessor
Market segment
Mobile
Family
c i7 Mobile
Frequency?
2800 MHz
Maximum turbo frequency
3500 MHz (1 c)
3300 MHz (2 cores)
Clock multiplier?
28
Package
988-pin micro-PGA (rPGA988B)
Socket
Socket G2 / rPGA988B
S-spec numbers
Part number
Production processors
SR03R
FF8062700838905
+
Architecture / Microarchitecture
Microarchitecture
Sandy Bridge
Processor c?
Sandy Bridge
c stepping?
J1 (SR03R)
CPUID
206A7 (SR03R)
Manufacturing process
0.032 micron High-K metal gate process
Data width
64 bit
The number of CPU cores
2
The number of threads
4
Floating Point Unit
Integrated
Level 1 cache size?
2 x 32 KB 8-way set associative instruction caches
2 x 32 KB 8-way set associative data caches
Level 2 cache size?
2 x 256 KB 8-way set associative caches
Level 3 cache size
4 MB 16-way set associative shared cache
Physical memory
16 GB
Multiprocessing
Not supported
Extensions and Technologies
MMX instructions
SSE / Streaming SIMD Extensions
SSE2 / Streaming SIMD Extensions 2
SSE3 / Streaming SIMD Extensions 3
SSSE3 / Supplemental Streaming SIMD Extensions 3
SSE4 / SSE4.1 + SSE4.2 / Streaming SIMD Extensions 4?
AES / Advanced Encryption Standard instructions
AVX / Advanced Vector Extensions
EM64T / Extended Memory 64 technology / I 64?
NX / XD / Execute disable bit?
HT / Hyper-Threading technology?
TBT 2.0 / Turbo Boost technology 2.0?
VT-x / Virtualization technology?
VT-d / Virtualization for directed I/O
TXT / Trusted Execution technology
Low power features
Enhanced / technology?
Integrated peripherals / components
Integrated graphics
GPU Type: HD 3000
Microarchitecture: Gen 6
Execution units: 12
Base frequency (MHz): 650
Maximum frequency (MHz): 1300
The number of supported displays: 2
Memory controller
The number of controllers: 1
Memory channels: 2
Supported memory: DDR3-1066, DDR3-1333
Maximum memory bandwidth (GB/s): 21.3
Other peripherals
Direct Media Interface 2.0
PCI Express 2.0 interface
Electrical / Thermal parameters
Maximum operating temperature?
100°C
Thermal Design Power?
35 Watt
